Nexel Wire and Solid Shelving
Specs and Warranty Page
Nexel Shelving, Wire Shelves, Industrial Racks
Nexel Product Performance Warranty
Nexel Industries, Inc. warrants that all Nexel products will be free from defects in material and manufacture at time of shipment. Nexel guarantees to replace any item that is found to be defective for up to one (1) year from date of shipment provided that it has been properly used. See "Finishes" below for extended warranties on the different finishes.
Nexel will repair or replace any product that does not perform as represented herein with normal usage. A Nexel representative will examine the installation and determine repair or return disposition. Customer may need to shipped affected items to Nexel for examination. Replacements will be shipped prepaid. No returns may be made without written authorization.
All warranties are made for the benefit of the original owner under normal usage. There are no other warranties expressed or implied beyond those stated herein. No employee or agent of Nexel has any authority to make any representation or warranty which exceeds those stated above.
The manufacturer reserves the right to inspect the merchandise before issuing any type of credit. Damaged items will be replaced at no cost to customer UNLESS,
- the damage is not noted on the shippers paperwork
- we are not notified within 15 days of receipt of product
- items are not returned within 30 days from ship date
- items are not returned in the original packaging
- items were damaged through improper installation or use
Load Capacities for Shelving
Solid Shelves |
up to 600 lbs/shelf |
Wire Shelves |
42" and less: 800 lbs/shelf 48" and longer: 600 lbs/shelf |
E-Z Adjust Wire Shelves |
up to 400 lbs/shelf |
Extra Wide Wire Shelves |
up to 600 lbs/shelf |
Nexelite Polymer Shelves |
up to 600 lbs/shelf |
Solid Plastic Shelves |
up to 300 lbs/shelf |
View complete weight capacity chart
| Specs | |
| Posts | 1" in diameter. Adjustable on 1" increments. Numbered every 1". |
| Shelf Mat Wires | #9 wire (.1483" dia.) on .7917" centers. #6 wire (.192" dia.) used for shelf support wires. |
| Wire Shelf Frames | 1/4 rod (.25" dia.) on frame. 1/4" rod acts as natural frame to help prevent items from falling off. |
| Shelf Clips | Two piece plastic split sleeve. |
| Shelf Collar | Tapered collar snugly locks on tapered plastic split sleeves. |
| Strength and Shelf Deflection | Shelf widths of 42" and less will hold up to 800 lbs each. Shelves 48" and longer will hold up to 600 lbs each. Weight must be evenly distributed. |
| Chrome Electroplating Thickness | .0001 avg. |
* (Weight must be static and evenly distributed)
Click the links on this page
to view prices or
to add product to your shopping cart.
| Wire Shelves (D" x W") - available in all finishes (except where noted) | |||
14" Deep (No SS*) |
18" Deep |
21" Deep |
24" Deep |
| Extra Wide Wire Shelf Sizes | |||
30" Deep (Chrome only*) |
36" Deep (Chrome only*) |
||
| (All sizes listed are nominal) | |||
| Posts (Height) | |||
| 6"H (No SS*) |
14"H (No SS*) |
34"H (No SS*) |
42" (Chrome only*) |
| 54"H (Chrome and Nexelon only*) |
63"H (All finishes*) |
66"H (Chrome and Poly only*) |
74"H (All finishes*) |
| 86"H (All finishes*) |
96"H (Chrome only*) |
* Some heights available in certain finishes only SS = Stainless Steel Poly = Poly-Z-Brite EP = Silver Epoxy |
|
(All photographs are representations only. Nexel reserves the right to change the design, style, materials, etc., which may alter the appearance of the product.
All sizes listed are nominal)
